Long description:
High throughput & High accuracy
- It is optimized for higher throughput, enhanced efficiency, and easy operation
- Easy guidance for any operators
- Showing Jam point in the screen
- Automatic assisted feeding mechanism
- Descending type stacker pocket
- Extension 4 pockets (Optional)
- Automated banding function (Optional)
Specifications
| Currency | No limit currency |
| MIX : up to 30 currency | |
| Operation Speed | Max 1,200 banknotes / min |
| MAX : 72,000 banknotes / hour | |
| Pocket Capacity | Hopper : 1,200 notes |
| Stacker : 500 notes with 4 stacker | |
| Reject : 250 notes with 2 reject | |
| (1 reject pocket is changeable as stacker) | |
| Sensor information | Dual Image Sensor with Full line UV,
Infrared, Magnetic, Thickness Sensor (Mechanic) |
| Banknote size | 60-85mm(V) x 100~177mm(H) |
| Dimension | 860(W) x 425(D) x 680(H) mm |
| Weight | 86Kgs, 120Kgs (Gross) |
